NC7ST02P5X

Part No :: NC7ST02P5X

Manufacturer: VIGOR

VIGOR # :: 3821814

Description: IC GATE NOR 1CH 2-INP SC70-5

Catalog: Logic - Gates and Inverters

DataSheet: NC7ST02P5X PDF

Country of origin: -

Date code: -

NC7ST02P5X Specifications

Type	Description
Series:	7ST
Package:	Bulk
Part Status:	Active
Logic Type:	NOR Gate
Number of Circuits:	1
Number of Inputs:	2
Features:	-
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	1 µA
Current - Output High, Low:	2mA, 2mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	26ns @ 5.5V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	SC-70-5
Package / Case:	5-TSSOP, SC-70-5, SOT-353

Alternative Products

Part Number	Manufacturer & Description	Compare
NC7ST08P5X Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE AND 1CH 2-INP SC70-5	NC7ST02P5X vs NC7ST08P5X
NC7ST00P5X Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NAND 1CH 2-INP SC70-5	NC7ST02P5X vs NC7ST00P5X
NC7ST32P5X Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE OR 1CH 2-INP SC70-5	NC7ST02P5X vs NC7ST32P5X
NC7ST08P5 Match 100%	VIGOR IC GATE AND 1CH 2-INP SC70-5	NC7ST02P5X vs NC7ST08P5
NC7ST00P5 Match 100%	VIGOR IC GATE NAND 1CH 2-INP SC70-5	NC7ST02P5X vs NC7ST00P5
NC7ST02P5 Match 100%	VIGOR IC GATE NOR 1CH 2-INP SC70-5	NC7ST02P5X vs NC7ST02P5
