SN74S05D

Part No :: SN74S05D

Manufacturer: Texas Instruments

VIGOR # :: 3822313

Description: IC INVERTER OPEN 6CH 6-IN 14SOIC

Catalog: Logic - Gates and Inverters

DataSheet: SN74S05D PDF

Country of origin: -

Date code: -

SN74S05D Specifications

Type	Description
Series:	74S
Package:	Tube
Part Status:	Active
Logic Type:	Inverter
Number of Circuits:	6
Number of Inputs:	6
Features:	Open Collector
Voltage - Supply:	4.75V ~ 5.25V
Current - Quiescent (Max):	-
Current - Output High, Low:	-, 20mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	7.5ns @ 5V, 50pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)
