MC74ACT20DG

Part No :: MC74ACT20DG

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 3822515

Description: IC GATE NAND 2CH 4-INP 14SOIC

Catalog: Logic - Gates and Inverters

DataSheet: MC74ACT20DG PDF

Country of origin: -

Date code: -

MC74ACT20DG Specifications

Type	Description
Series:	74ACT
Package:	Tube
Part Status:	Active
Logic Type:	NAND Gate
Number of Circuits:	2
Number of Inputs:	4
Features:	-
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	4 µA
Current - Output High, Low:	24mA, 24mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	9ns @ 5V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)
