SN74HC20DBRE4

Part No :: SN74HC20DBRE4

Manufacturer: Texas Instruments

VIGOR # :: 4884360

Description: IC GATE NAND 2CH 4-INP 14SSOP

Catalog: Logic - Gates and Inverters

DataSheet: SN74HC20DBRE4 PDF

Country of origin: -

Date code: -

SN74HC20DBRE4 Specifications

Type	Description
Series:	74HC
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Logic Type:	NAND Gate
Number of Circuits:	2
Number of Inputs:	4
Features:	-
Voltage - Supply:	2V ~ 6V
Current - Quiescent (Max):	2 µA
Current - Output High, Low:	5.2mA, 5.2mA
Logic Level - Low:	0.5V ~ 1.8V
Logic Level - High:	1.5V ~ 4.2V
Max Propagation Delay @ V, Max CL:	19ns @ 6V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SSOP
Package / Case:	14-SSOP (0.209", 5.30mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
74HC21DB,112-NXP Match 100%	VIGOR IC GATE AND 2CH 4-INP 14SSOP	SN74HC20DBRE4 vs 74HC21DB,112-NXP
SN74HC20DBR Match 100%	VIGOR IC GATE NAND 2CH 4-INP 14SSOP	SN74HC20DBRE4 vs SN74HC20DBR
74HC21DB,118 Match 100%	VIGOR IC GATE AND 2CH 4-INP 14SSOP	SN74HC20DBRE4 vs 74HC21DB,118
74HC21DB,112 Match 100%	VIGOR IC GATE AND 2CH 4-INP 14SSOP	SN74HC20DBRE4 vs 74HC21DB,112
SN74HC20DBRG4 Match 100%	Texas Instruments IC GATE NAND 2CH 4-INP 14SSOP	SN74HC20DBRE4 vs SN74HC20DBRG4
74HC21DB,118-NEX Match 100%	VIGOR IC GATE AND 2CH 4-INP 14SSOP	SN74HC20DBRE4 vs 74HC21DB,118-NEX
