SN74ALS20ADBRG4

Part No :: SN74ALS20ADBRG4

Manufacturer: Texas Instruments

VIGOR # :: 4884960

Description: IC GATE NAND 2CH 4-INP 14SSOP

Catalog: Logic - Gates and Inverters

DataSheet: SN74ALS20ADBRG4 PDF

Country of origin: -

Date code: -

SN74ALS20ADBRG4 Specifications

Type	Description
Series:	74ALS
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Logic Type:	NAND Gate
Number of Circuits:	2
Number of Inputs:	4
Features:	-
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	-
Current - Output High, Low:	400µA, 8mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	12.5ns @ 5V, 50pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SSOP
Package / Case:	14-SSOP (0.209", 5.30mm Width)
