MC74LVX02M

Part No :: MC74LVX02M

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4885151

Description: IC GATE NOR 4CH 2-INP SOEIAJ-14

Catalog: Logic - Gates and Inverters

DataSheet: MC74LVX02M PDF

Country of origin: -

Date code: -

MC74LVX02M Specifications

Type	Description
Series:	74LVX
Package:	Tube
Part Status:	Obsolete
Logic Type:	NOR Gate
Number of Circuits:	4
Number of Inputs:	2
Features:	-
Voltage - Supply:	2V ~ 3.6V
Current - Quiescent (Max):	2 µA
Current - Output High, Low:	4mA, 4mA
Logic Level - Low:	0.5V ~ 0.8V
Logic Level - High:	1.5V ~ 2.4V
Max Propagation Delay @ V, Max CL:	10.1ns @ 3.3V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	SOEIAJ-14
Package / Case:	14-SOIC (0.209", 5.30mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
MC74LVX02MEL Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NOR 4CH 2-INP SOEIAJ-14	MC74LVX02M vs MC74LVX02MEL
MC74LVX32MELG Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE OR 4CH 2-INP SOEIAJ-14	MC74LVX02M vs MC74LVX32MELG
MC74LVX32M Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE OR 4CH 2-INP SOEIAJ-14	MC74LVX02M vs MC74LVX32M
MC74LVX02MG Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NOR 4CH 2-INP SOEIAJ-14	MC74LVX02M vs MC74LVX02MG
MC74LVX02MELG Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE NOR 4CH 2-INP SOEIAJ-14	MC74LVX02M vs MC74LVX02MELG
MC74LVX32MG Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE OR 4CH 2-INP SOEIAJ-14	MC74LVX02M vs MC74LVX32MG
