SN74ALS09NSRG4

Part No :: SN74ALS09NSRG4

Manufacturer: Texas Instruments

VIGOR # :: 4885262

Description: IC GATE AND OP COL 4CH 2IN 14SOP

Catalog: Logic - Gates and Inverters

DataSheet: SN74ALS09NSRG4 PDF

Country of origin: -

Date code: -

SN74ALS09NSRG4 Specifications

Type	Description
Series:	74ALS
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Logic Type:	AND Gate
Number of Circuits:	4
Number of Inputs:	2
Features:	Open Collector
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	-
Current - Output High, Low:	-, 8mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	54ns @ 5V, 50pF
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOP
Package / Case:	14-SOIC (0.209", 5.30mm Width)
