MC74HC86AN

Part No :: MC74HC86AN

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4885528

Description: IC GATE XOR 4CH 2-INP 14DIP

Catalog: Logic - Gates and Inverters

DataSheet: MC74HC86AN PDF

Country of origin: -

Date code: -

MC74HC86AN Specifications

Type	Description
Series:	74HC
Package:	Tube
Part Status:	Obsolete
Logic Type:	XOR (Exclusive OR)
Number of Circuits:	4
Number of Inputs:	2
Features:	-
Voltage - Supply:	2V ~ 6V
Current - Quiescent (Max):	1 µA
Current - Output High, Low:	5.2mA, 5.2mA
Logic Level - Low:	0.5V ~ 1.8V
Logic Level - High:	1.5V ~ 4.2V
Max Propagation Delay @ V, Max CL:	17ns @ 6V, 50pF
Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Through Hole
Supplier Device Package:	14-PDIP
Package / Case:	14-DIP (0.300", 7.62mm)
