MC14504BFG

Part No :: MC14504BFG

Manufacturer: VIGOR

VIGOR # :: 3885528

Description: TTL/CMOS TO CMOS TRANSLATOR

Catalog: Logic - Translators, Level Shifters

DataSheet: MC14504BFG PDF

Country of origin: -

Date code: -

MC14504BFG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Translator Type:	Voltage Level
Channel Type:	Unidirectional
Number of Circuits:	1
Channels per Circuit:	6
Voltage - VCCA:	3 V ~ 18.0 V
Voltage - VCCB:	3 V ~ 18.0 V
Input Signal:	-
Output Signal:	-
Output Type:	Non-Inverted
Data Rate:	-
Operating Temperature:	-55°C ~ 125°C (TA)
Features:	-
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.209", 5.30mm Width)
Supplier Device Package:	16-SOEIAJ
