MC14504BDTR2

Part No :: MC14504BDTR2

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4910651

Description: IC TRNSLTR UNIDIR 16TSSOP

Catalog: Logic - Translators, Level Shifters

DataSheet: MC14504BDTR2 PDF

Country of origin: -

Date code: -

MC14504BDTR2 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Translator Type:	Voltage Level
Channel Type:	Unidirectional
Number of Circuits:	1
Channels per Circuit:	6
Voltage - VCCA:	3 V ~ 18.0 V
Voltage - VCCB:	3 V ~ 18.0 V
Input Signal:	-
Output Signal:	-
Output Type:	Non-Inverted
Data Rate:	-
Operating Temperature:	-55°C ~ 125°C (TA)
Features:	-
Mounting Type:	Surface Mount
Package / Case:	16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:	16-TSSOP

Alternative Products

Part Number	Manufacturer & Description	Compare
CD4504BPWR Match 100%	Texas Instruments IC TRNSLTR UNIDIR 16TSSOP	MC14504BDTR2 vs CD4504BPWR
CD4504BMPWREP Match 100%	Texas Instruments IC TRNSLTR UNIDIR 16TSSOP	MC14504BDTR2 vs CD4504BMPWREP
CD4504BPW Match 100%	Texas Instruments IC TRNSLTR UNIDIR 16TSSOP	MC14504BDTR2 vs CD4504BPW
CD4504BPWE4 Match 100%	Texas Instruments IC TRNSLTR UNIDIR 16TSSOP	MC14504BDTR2 vs CD4504BPWE4
NLV14504BDTG Match 100%	Sanyo Semiconductor/ON Semiconductor IC TRNSLTR UNIDIR 16TSSOP	MC14504BDTR2 vs NLV14504BDTG
MC14504BDTG Match 100%	Sanyo Semiconductor/ON Semiconductor IC TRNSLTR UNIDIR 16TSSOP	MC14504BDTR2 vs MC14504BDTG
