UCC3804NG4

Part No :: UCC3804NG4

Manufacturer: Texas Instruments

VIGOR # :: 3932178

Description: IC REG CTRLR PWM CM 8DIP

Catalog: PMIC - AC DC Converters, Offline Switchers

DataSheet: UCC3804NG4 PDF

Country of origin: -

Date code: -

UCC3804NG4 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Isolation:	-
Internal Switch(s):	No
Voltage - Breakdown:	-
Topology:	Boost, Buck, Flyback, Forward
Voltage - Start Up:	12.5 V
Voltage - Supply (Vcc/Vdd):	8.3V ~ 12V
Duty Cycle:	49%
Frequency - Switching:	Up to 1MHz
Power (Watts):	-
Fault Protection:	Current Limiting
Control Features:	Frequency Control
Operating Temperature:	-40°C ~ 85°C (TA)
Package / Case:	8-DIP (0.300", 7.62mm)
Supplier Device Package:	8-PDIP
Mounting Type:	Through Hole
