UCC3580D-2

Part No :: UCC3580D-2

Manufacturer: VIGOR

VIGOR # :: 3932257

Description: UCC3580 - SINGLE-ENDED ACTIVE CL

Catalog: PMIC - AC DC Converters, Offline Switchers

DataSheet: UCC3580D-2 PDF

Country of origin: -

Date code: -

UCC3580D-2 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Output Isolation:	Isolated
Internal Switch(s):	No
Voltage - Breakdown:	-
Topology:	Flyback, Forward
Voltage - Start Up:	15 V
Voltage - Supply (Vcc/Vdd):	8.5V ~ 15V
Duty Cycle:	66%
Frequency - Switching:	-
Power (Watts):	-
Fault Protection:	-
Control Features:	Soft Start
Operating Temperature:	-55°C ~ 150°C (TJ)
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC
Mounting Type:	Surface Mount
