TOP269KG

Part No :: TOP269KG

Manufacturer: Power Integrations

Description: IC OFFLINE SW 55W 81W 12ESOP

Catalog: PMIC - AC DC Converters, Offline Switchers

DataSheet: TOP269KG PDF

Availability: 1642 pieces

Unit Price: ~~$2.46000~~

Current price of TOP269KG is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

TOP269KG Specifications

Type	Description
Series:	TOPSwitch®-JX
Package:	Tube
Part Status:	Discontinued at Digi-Key
Output Isolation:	Isolated
Internal Switch(s):	Yes
Voltage - Breakdown:	725V
Topology:	Flyback
Voltage - Start Up:	-
Voltage - Supply (Vcc/Vdd):	-
Duty Cycle:	78%
Frequency - Switching:	66kHz, 132kHz
Power (Watts):	81 W
Fault Protection:	Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit
Control Features:	Frequency Control
Operating Temperature:	-40°C ~ 150°C (TJ)
Package / Case:	12-BESOP (0.350", 8.89mm Width), 11 Leads, Exposed Pad
Supplier Device Package:	12-ESOP
Mounting Type:	Surface Mount

Please confirm the specifications of the products when ordering.
