TPS2814DR

Part No :: TPS2814DR

Manufacturer: Texas Instruments

VIGOR # :: 3879078

Description: IC GATE DRVR LOW-SIDE 8SOIC

Catalog: PMIC - Gate Drivers

DataSheet: TPS2814DR PDF

Country of origin: -

Date code: -

TPS2814DR Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Driven Configuration:	Low-Side
Channel Type:	Synchronous
Number of Drivers:	2
Gate Type:	N-Channel, P-Channel MOSFET
Voltage - Supply:	4V ~ 14V
Logic Voltage - VIL, VIH:	1V, 4V
Current - Peak Output (Source, Sink):	2A, 2A
Input Type:	Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap):	-
Rise / Fall Time (Typ):	14ns, 15ns
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
