EL7156CNZ

Part No :: EL7156CNZ

Manufacturer: VIGOR

Description: HALF BRIDGE PERIPHERAL DRIVER

Catalog: PMIC - Gate Drivers

DataSheet: EL7156CNZ PDF

Availability: 180 pieces

Unit Price: ~~$5.16000~~

Current price of EL7156CNZ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

EL7156CNZ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Driven Configuration:	High-Side or Low-Side
Channel Type:	Single
Number of Drivers:	1
Gate Type:	IGBT
Voltage - Supply:	4.5V ~ 16.5V
Logic Voltage - VIL, VIH:	0.8V, 2.4V
Current - Peak Output (Source, Sink):	3.5A, 3.5A
Input Type:	Non-Inverting
High Side Voltage - Max (Bootstrap):	-
Rise / Fall Time (Typ):	14.5ns, 15ns
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Through Hole
Package / Case:	8-DIP (0.300", 7.62mm)
Supplier Device Package:	8-PDIP
