1EDN7511BXUSA1

Part No :: 1EDN7511BXUSA1

Manufacturer: IR (Infineon Technologies)

VIGOR # :: 3879243

Description: IC GATE DRV HALF BRD/LOW SOT23-6

Catalog: PMIC - Gate Drivers

DataSheet: 1EDN7511BXUSA1 PDF

Country of origin: -

Date code: -

1EDN7511BXUSA1 Specifications

Type	Description
Series:	EiceDriver™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Driven Configuration:	Half-Bridge, Low-Side
Channel Type:	Single
Number of Drivers:	1
Gate Type:	N-Channel, P-Channel MOSFET
Voltage - Supply:	4.5V ~ 20V
Logic Voltage - VIL, VIH:	1.2V, 1.9V
Current - Peak Output (Source, Sink):	4A, 8A
Input Type:	Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap):	-
Rise / Fall Time (Typ):	6.5ns, 4.5ns
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	SOT-23-6
Supplier Device Package:	PG-SOT23-6-2
