LM5101CSD/NOPB

Part No :: LM5101CSD/NOPB

Manufacturer: Texas Instruments

Description: IC GATE DRVR HALF-BRIDGE 10WSON

Catalog: PMIC - Gate Drivers

DataSheet: LM5101CSD/NOPB PDF

Availability: 1010 pieces

Current price of LM5101CSD/NOPB is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

LM5101CSD/NOPB Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Driven Configuration:	Half-Bridge
Channel Type:	Independent
Number of Drivers:	2
Gate Type:	N-Channel MOSFET
Voltage - Supply:	9V ~ 14V
Logic Voltage - VIL, VIH:	2.3V, -
Current - Peak Output (Source, Sink):	1A, 1A
Input Type:	Non-Inverting
High Side Voltage - Max (Bootstrap):	118 V
Rise / Fall Time (Typ):	990ns, 715ns
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	10-WDFN Exposed Pad
Supplier Device Package:	10-WSON (4x4)
