2ED020I12-F

Part No :: 2ED020I12-F

Manufacturer: VIGOR

VIGOR # :: 3879903

Description: HALF-BRIDGE PERIPHERAL DRIVER

Catalog: PMIC - Gate Drivers

DataSheet: 2ED020I12-F PDF

Country of origin: -

Date code: -

2ED020I12-F Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Driven Configuration:	Half-Bridge
Channel Type:	Independent
Number of Drivers:	2
Gate Type:	IGBT, N-Channel MOSFET
Voltage - Supply:	0V ~ 18V
Logic Voltage - VIL, VIH:	-
Current - Peak Output (Source, Sink):	1A, 2A
Input Type:	Inverting
High Side Voltage - Max (Bootstrap):	1.2 V
Rise / Fall Time (Typ):	-
Operating Temperature:	-
Mounting Type:	Surface Mount
Package / Case:	20-SOIC (0.295", 7.50mm Width), 18 Leads
Supplier Device Package:	PG-DSO-18-2
