6ED2230S12TXUMA1

Part No :: 6ED2230S12TXUMA1

Manufacturer: IR (Infineon Technologies)

VIGOR # :: 3880034

Description: 1200V THREE PHASE DRIVER

Catalog: PMIC - Gate Drivers

DataSheet: 6ED2230S12TXUMA1 PDF

Country of origin: -

Date code: -

6ED2230S12TXUMA1 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Driven Configuration:	High-Side or Low-Side
Channel Type:	3-Phase
Number of Drivers:	6
Gate Type:	IGBT, N-Channel MOSFET
Voltage - Supply:	10V ~ 20V
Logic Voltage - VIL, VIH:	0.7V, 2.3V
Current - Peak Output (Source, Sink):	350mA, 650mA
Input Type:	Inverting
High Side Voltage - Max (Bootstrap):	1200 V
Rise / Fall Time (Typ):	35ns, 20ns
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	28-SOIC (0.295", 7.50mm Width), 24 Leads
Supplier Device Package:	PG-DSO-24
