2ED020I12F2XUMA1

Part No :: 2ED020I12F2XUMA1

Manufacturer: IR (Infineon Technologies)

VIGOR # :: 3881338

Description: IC GATE DRVR HALF-BRIDG DSO36-58

Catalog: PMIC - Gate Drivers

DataSheet: 2ED020I12F2XUMA1 PDF

Country of origin: -

Date code: -

2ED020I12F2XUMA1 Specifications

Type	Description
Series:	EiceDriver™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Driven Configuration:	Half-Bridge
Channel Type:	Independent
Number of Drivers:	2
Gate Type:	IGBT
Voltage - Supply:	13V ~ 20V
Logic Voltage - VIL, VIH:	1.5V, 3.5V
Current - Peak Output (Source, Sink):	2A, 2A
Input Type:	Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap):	1200 V
Rise / Fall Time (Typ):	30ns, 50ns
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	36-BSSOP (0.295", 7.50mm Width), 32 Leads
Supplier Device Package:	PG-DSO-36-58
