TPS2814PW

Part No :: TPS2814PW

Manufacturer: VIGOR

VIGOR # :: 3881396

Description: TPS2814 ONE INVERTING, ONE NON-I

Catalog: PMIC - Gate Drivers

DataSheet: TPS2814PW PDF

Country of origin: -

Date code: -

TPS2814PW Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Driven Configuration:	Low-Side
Channel Type:	Synchronous
Number of Drivers:	2
Gate Type:	N-Channel, P-Channel MOSFET
Voltage - Supply:	4V ~ 14V
Logic Voltage - VIL, VIH:	1V, 4V
Current - Peak Output (Source, Sink):	2A, 2A
Input Type:	Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap):	-
Rise / Fall Time (Typ):	14ns, 15ns
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:	8-TSSOP
