LM5114BMFX/S7003094

Part No :: LM5114BMFX/S7003094

Manufacturer: VIGOR

VIGOR # :: 3881525

Description: LM5114 SINGLE 7.6A PEAK CURRENT

Catalog: PMIC - Gate Drivers

DataSheet: LM5114BMFX/S7003094 PDF

Country of origin: -

Date code: -

LM5114BMFX/S7003094 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Driven Configuration:	Low-Side
Channel Type:	Single
Number of Drivers:	1
Gate Type:	N-Channel MOSFET
Voltage - Supply:	4V ~ 12.6V
Logic Voltage - VIL, VIH:	0.8V, 2.4V
Current - Peak Output (Source, Sink):	1.3A, 7.6A
Input Type:	Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap):	-
Rise / Fall Time (Typ):	82ns, 12.5ns
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	SOT-23-6
Supplier Device Package:	SOT-23-6
