DGD0506FN-7

Part No :: DGD0506FN-7

Manufacturer: Zetex Semiconductors (Diodes Inc.)

VIGOR # :: 3881708

Description: IC GATE DRV HALF-BRDG DFN3030-10

Catalog: PMIC - Gate Drivers

DataSheet: DGD0506FN-7 PDF

Country of origin: -

Date code: -

DGD0506FN-7 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Not For New Designs
Driven Configuration:	Half-Bridge
Channel Type:	Synchronous
Number of Drivers:	2
Gate Type:	N-Channel MOSFET
Voltage - Supply:	8V ~ 14V
Logic Voltage - VIL, VIH:	1V, 2.5V
Current - Peak Output (Source, Sink):	1.5A, 2.5A
Input Type:	Non-Inverting
High Side Voltage - Max (Bootstrap):	50 V
Rise / Fall Time (Typ):	17ns, 12ns
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	10-WFDFN Exposed Pad
Supplier Device Package:	W-DFN3030-10 (Type TH)
