NCD5701BDR2G

Part No :: NCD5701BDR2G

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 3881814

Description: IC GATE DRVR LOW-SIDE 8SOIC

Catalog: PMIC - Gate Drivers

DataSheet: NCD5701BDR2G PDF

Country of origin: -

Date code: -

NCD5701BDR2G Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Driven Configuration:	Low-Side
Channel Type:	Single
Number of Drivers:	1
Gate Type:	IGBT
Voltage - Supply:	20V
Logic Voltage - VIL, VIH:	-
Current - Peak Output (Source, Sink):	7.8A, 6.8A
Input Type:	-
High Side Voltage - Max (Bootstrap):	-
Rise / Fall Time (Typ):	18ns, 19ns
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
NCD5701CDR2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE DRVR HI/LOW SIDE 8SOIC	NCD5701BDR2G vs NCD5701CDR2G
NCV57080CDR2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC IGBT GATE DRIVER 8SOIC	NCD5701BDR2G vs NCV57080CDR2G
NCD5701ADR2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE DRVR LOW-SIDE 8SOIC	NCD5701BDR2G vs NCD5701ADR2G
