NCP3420MNR2G

Part No :: NCP3420MNR2G

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4908845

Description: IC GATE DRVR HALF-BRIDGE 8DFN

Catalog: PMIC - Gate Drivers

DataSheet: NCP3420MNR2G PDF

Country of origin: -

Date code: -

NCP3420MNR2G Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Driven Configuration:	Half-Bridge
Channel Type:	Synchronous
Number of Drivers:	2
Gate Type:	N-Channel MOSFET
Voltage - Supply:	4.6V ~ 13.2V
Logic Voltage - VIL, VIH:	0.8V, 2V
Current - Peak Output (Source, Sink):	-
Input Type:	Non-Inverting
High Side Voltage - Max (Bootstrap):	35 V
Rise / Fall Time (Typ):	16ns, 11ns
Operating Temperature:	0°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	8-VFDFN Exposed Pad
Supplier Device Package:	8-DFN (3x3)
