EL7156CS-T7

Part No :: EL7156CS-T7

Manufacturer: Intersil (Renesas Electronics America)

VIGOR # :: 4909217

Description: IC GATE DRVR HI/LOW SIDE 8SOIC

Catalog: PMIC - Gate Drivers

DataSheet: EL7156CS-T7 PDF

Country of origin: -

Date code: -

EL7156CS-T7 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Driven Configuration:	High-Side or Low-Side
Channel Type:	Single
Number of Drivers:	1
Gate Type:	IGBT
Voltage - Supply:	4.5V ~ 16.5V
Logic Voltage - VIL, VIH:	0.8V, 2.4V
Current - Peak Output (Source, Sink):	3.5A, 3.5A
Input Type:	Non-Inverting
High Side Voltage - Max (Bootstrap):	-
Rise / Fall Time (Typ):	14.5ns, 15ns
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
