IR2138QPBF

Part No :: IR2138QPBF

Manufacturer: IR (Infineon Technologies)

VIGOR # :: 4909713

Description: IC GATE DRVR HALF-BRIDGE 64MQFP

Catalog: PMIC - Gate Drivers

DataSheet: IR2138QPBF PDF

Country of origin: -

Date code: -

IR2138QPBF Specifications

Type	Description
Series:	-
Package:	Tray
Part Status:	Obsolete
Driven Configuration:	Half-Bridge
Channel Type:	3-Phase
Number of Drivers:	6
Gate Type:	IGBT
Voltage - Supply:	12.5V ~ 20V
Logic Voltage - VIL, VIH:	0.8V, 2V
Current - Peak Output (Source, Sink):	350mA, 200mA
Input Type:	Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap):	600 V
Rise / Fall Time (Typ):	80ns, 25ns
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	64-BQFP
Supplier Device Package:	64-MQFP (20x14)
