LM5100CSDX

Part No :: LM5100CSDX

Manufacturer: Texas Instruments

VIGOR # :: 4909788

Description: IC GATE DRVR HALF-BRIDGE 10WSON

Catalog: PMIC - Gate Drivers

DataSheet: LM5100CSDX PDF

Country of origin: -

Date code: -

LM5100CSDX Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Driven Configuration:	Half-Bridge
Channel Type:	Independent
Number of Drivers:	2
Gate Type:	N-Channel MOSFET
Voltage - Supply:	9V ~ 14V
Logic Voltage - VIL, VIH:	2.3V, -
Current - Peak Output (Source, Sink):	1A, 1A
Input Type:	Non-Inverting
High Side Voltage - Max (Bootstrap):	118 V
Rise / Fall Time (Typ):	990ns, 715ns
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	10-WDFN Exposed Pad
Supplier Device Package:	10-WSON (4x4)
