ISL6614IRZ-TR5238

Part No :: ISL6614IRZ-TR5238

Manufacturer: Intersil (Renesas Electronics America)

VIGOR # :: 4909904

Description: IC GATE DRVR HALF-BRIDGE 16QFN

Catalog: PMIC - Gate Drivers

DataSheet: ISL6614IRZ-TR5238 PDF

Country of origin: -

Date code: -

ISL6614IRZ-TR5238 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Driven Configuration:	Half-Bridge
Channel Type:	Synchronous
Number of Drivers:	4
Gate Type:	N-Channel MOSFET
Voltage - Supply:	10.8V ~ 13.2V
Logic Voltage - VIL, VIH:	-
Current - Peak Output (Source, Sink):	1.25A, 2A
Input Type:	Non-Inverting
High Side Voltage - Max (Bootstrap):	36 V
Rise / Fall Time (Typ):	26ns, 18ns
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	16-VQFN Exposed Pad
Supplier Device Package:	16-QFN (4x4)
