L6569AD013TR

Part No :: L6569AD013TR

Manufacturer: STMicroelectronics

VIGOR # :: 4909987

Description: IC GATE DRVR HALF-BRIDGE 8SO

Catalog: PMIC - Gate Drivers

DataSheet: L6569AD013TR PDF

Country of origin: -

Date code: -

L6569AD013TR Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Obsolete
Driven Configuration:	Half-Bridge
Channel Type:	Synchronous
Number of Drivers:	2
Gate Type:	IGBT, N-Channel MOSFET
Voltage - Supply:	10V ~ 16.6V
Logic Voltage - VIL, VIH:	-
Current - Peak Output (Source, Sink):	170mA, 270mA
Input Type:	RC Input Circuit
High Side Voltage - Max (Bootstrap):	600 V
Rise / Fall Time (Typ):	-
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SO
