MAX16814ATP/V+TC81

Part No :: MAX16814ATP/V+TC81

Manufacturer: Maxim Integrated

VIGOR # :: 4920076

Description: INTEGRATED, 4-CHANNEL, HIGH-BRIG

Catalog: PMIC - LED Drivers

DataSheet: MAX16814ATP/V+TC81 PDF

Country of origin: -

Date code: -

MAX16814ATP/V+TC81 Specifications

Type	Description
Series:	Automotive, AEC-Q100
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	DC DC Controller
Topology:	SEPIC, Step-Down (Buck), Step-Up (Boost)
Internal Switch(s):	No
Number of Outputs:	4
Voltage - Supply (Min):	4.75V
Voltage - Supply (Max):	40V
Voltage - Output:	-
Current - Output / Channel:	150mA
Frequency:	200kHz ~ 2MHz
Dimming:	PWM
Applications:	Automotive, Backlight, Lighting
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	20-WFQFN Exposed Pad
Supplier Device Package:	20-TQFN (4x4)

Alternative Products

Part Number	Manufacturer & Description	Compare
MAX16838BATP/V+T Match 100%	Maxim Integrated INTEGRATED 2-CHANNEL HIGH-BRIGHT	MAX16814ATP/V+TC81 vs MAX16838BATP/V+T
MAX16814CATP/V+ Match 100%	Maxim Integrated INTEGRATED, 4-CHANNEL, HIGH-BRIG	MAX16814ATP/V+TC81 vs MAX16814CATP/V+
MAX16838BAUP+ Match 100%	Maxim Integrated IC LED DRIVER RGLTR DIM 20TSSOP	MAX16814ATP/V+TC81 vs MAX16838BAUP+
MAX16838BATP/V+ Match 100%	Maxim Integrated INTEGRATED 2-CHANNEL HIGH-BRIGHT	MAX16814ATP/V+TC81 vs MAX16838BATP/V+
MAX16813BATP/V+T Match 100%	Maxim Integrated INTEGRATED, 4-CHANNEL, HIGH-BRIG	MAX16814ATP/V+TC81 vs MAX16813BATP/V+T
MAX16838AUP+T Match 100%	Maxim Integrated IC LED DRIVER RGLTR DIM 20TSSOP	MAX16814ATP/V+TC81 vs MAX16838AUP+T
