TMC223-SI

Part No :: TMC223-SI

Manufacturer: TRINAMIC Motion Control GmbH

VIGOR # :: 4919392

Description: IC MTR DRV BIPOLAR 3.3-5V 20SOIC

Catalog: PMIC - Motor Drivers, Controllers

DataSheet: TMC223-SI PDF

Country of origin: -

Date code: -

TMC223-SI Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Motor Type - Stepper:	Bipolar
Motor Type - AC, DC:	-
Function:	Driver - Fully Integrated, Control and Power Stage
Output Configuration:	Half Bridge (4)
Interface:	I²C
Technology:	Power MOSFET
Step Resolution:	1, 1/2, 1/4, 1/8, 1/16
Applications:	General Purpose
Current - Output:	570mA
Voltage - Supply:	3.3V ~ 5V
Voltage - Load:	8V ~ 29V
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	20-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	20-SOIC
