NCP45520IMNTWG-H

Part No :: NCP45520IMNTWG-H

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 3866141

Description: IC PWR SWITCH N-CHAN 1:1 8DFN

Catalog: PMIC - Power Distribution Switches, Load Drivers

DataSheet: NCP45520IMNTWG-H PDF

Country of origin: -

Date code: -

NCP45520IMNTWG-H Specifications

Type	Description
Series:	ecoSWITCH™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Switch Type:	General Purpose
Number of Outputs:	1
Ratio - Input:Output:	1:1
Output Configuration:	High Side
Output Type:	N-Channel
Interface:	On/Off
Voltage - Load:	0.5V ~ 13.5V
Voltage - Supply (Vcc/Vdd):	3V ~ 5.5V
Current - Output (Max):	10.5A
Rds On (Typ):	12.8mOhm
Input Type:	Non-Inverting
Features:	Slew Rate Controlled
Fault Protection:	Over Temperature, UVLO
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	8-DFN (2x2)
Package / Case:	8-VFDFN Exposed Pad
