L6376D

Image is for reference,
please contact us to get the real picture

Part No :: L6376D

Manufacturer: STMicroelectronics

Description: IC PWR SWITCH N-CHAN 1:1 PWRSO20

Catalog: PMIC - Power Distribution Switches, Load Drivers

DataSheet: L6376D PDF

Availability: 31550 pieces

Unit Price: ~~$8.43000~~

Current price of L6376D is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

L6376D Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Switch Type:	General Purpose
Number of Outputs:	4
Ratio - Input:Output:	1:1
Output Configuration:	High Side
Output Type:	N-Channel
Interface:	On/Off
Voltage - Load:	9.5V ~ 35V
Voltage - Supply (Vcc/Vdd):	Not Required
Current - Output (Max):	500mA
Rds On (Typ):	-
Input Type:	Non-Inverting
Features:	Status Flag
Fault Protection:	Current Limiting (Fixed), Over Temperature, UVLO
Operating Temperature:	-25°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PowerSO-20
Package / Case:	20-SOIC (0.433", 11.00mm Width) Exposed Pad

Please confirm the specifications of the products when ordering.
