DS3680M

Part No :: DS3680M

Manufacturer: Texas Instruments

VIGOR # :: 4902361

Description: IC PWR DRIVER BIPOLAR 1:1 14SOIC

Catalog: PMIC - Power Distribution Switches, Load Drivers

DataSheet: DS3680M PDF

Country of origin: -

Date code: -

DS3680M Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Type:	Relay, Solenoid Driver
Number of Outputs:	4
Ratio - Input:Output:	1:1
Output Configuration:	High Side
Output Type:	Bipolar
Interface:	-
Voltage - Load:	-10V ~ -60V
Voltage - Supply (Vcc/Vdd):	-
Current - Output (Max):	50mA
Rds On (Typ):	-
Input Type:	Differential
Features:	-
Fault Protection:	-
Operating Temperature:	-25°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	14-SOIC
Package / Case:	14-SOIC (0.154", 3.90mm Width)
