UDN2559EB

Part No :: UDN2559EB

Manufacturer: Allegro MicroSystems

VIGOR # :: 4902504

Description: IC PWR DRIVER BIPOLAR 1:1 28PLCC

Catalog: PMIC - Power Distribution Switches, Load Drivers

DataSheet: UDN2559EB PDF

Country of origin: -

Date code: -

UDN2559EB Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Type:	General Purpose
Number of Outputs:	4
Ratio - Input:Output:	1:1
Output Configuration:	Low Side
Output Type:	Bipolar
Interface:	On/Off
Voltage - Load:	60V (Max)
Voltage - Supply (Vcc/Vdd):	4.75V ~ 5.25V
Current - Output (Max):	700mA
Rds On (Typ):	-
Input Type:	Non-Inverting
Features:	-
Fault Protection:	Current Limiting (Fixed), Over Temperature
Operating Temperature:	-20°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	28-PLCC (11.51x11.51)
Package / Case:	28-LCC (J-Lead)
