UDK2559B

Part No :: UDK2559B

Manufacturer: Allegro MicroSystems

VIGOR # :: 4903186

Description: IC PWR DRIVER BIPOLAR 1:1 16DIP

Catalog: PMIC - Power Distribution Switches, Load Drivers

DataSheet: UDK2559B PDF

Country of origin: -

Date code: -

UDK2559B Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Type:	General Purpose
Number of Outputs:	4
Ratio - Input:Output:	1:1
Output Configuration:	Low Side
Output Type:	Bipolar
Interface:	On/Off
Voltage - Load:	60V (Max)
Voltage - Supply (Vcc/Vdd):	4.75V ~ 5.25V
Current - Output (Max):	700mA
Rds On (Typ):	-
Input Type:	Non-Inverting
Features:	-
Fault Protection:	Current Limiting (Fixed), Over Temperature
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Through Hole
Supplier Device Package:	16-DIP
Package / Case:	16-PowerDIP (0.300", 7.62mm)
