LM336Z5

Part No :: LM336Z5

Manufacturer: VIGOR

VIGOR # :: 3718203

Description: TWO TERMINAL VOLTAGE REFERENCE,

Catalog: PMIC - Voltage Reference

DataSheet: LM336Z5 PDF

Country of origin: -

Date code: -

LM336Z5 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Reference Type:	Shunt
Output Type:	Fixed
Voltage - Output (Min/Fixed):	5V
Voltage - Output (Max):	-
Current - Output:	15 mA
Tolerance:	±4%
Temperature Coefficient:	-
Noise - 0.1Hz to 10Hz:	-
Noise - 10Hz to 10kHz:	-
Voltage - Input:	-
Current - Supply:	-
Current - Cathode:	10 mA
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Through Hole
Package / Case:	TO-226-3, TO-92-3 (TO-226AA)
Supplier Device Package:	TO-92-3

Alternative Products

Part Number	Manufacturer & Description	Compare
LM336Z-2.5/LFT7 Match 67%	Texas Instruments IC VREF SHUNT 4% TO92-3	LM336Z5 vs LM336Z-2.5/LFT7
LM336Z-2.5/NOPB Match 67%	Texas Instruments IC VREF SHUNT 4% TO92-3	LM336Z5 vs LM336Z-2.5/NOPB
LM336LPE3-2-5 Match 67%	VIGOR LM336-2.5 2.5-V INTEGRATED REFER	LM336Z5 vs LM336LPE3-2-5
LM336Z-2.5/LFT3 Match 67%	Texas Instruments IC VREF SHUNT 4% TO92-3	LM336Z5 vs LM336Z-2.5/LFT3
LM336Z-2.5/LFT1 Match 67%	Texas Instruments IC VREF SHUNT 4% TO92-3	LM336Z5 vs LM336Z-2.5/LFT1
LM336LP-2-5 Match 67%	VIGOR LM336-2.5 2.5-V INTEGRATED REFER	LM336Z5 vs LM336LP-2-5
