LM336DR-2-5

Part No :: LM336DR-2-5

Manufacturer: Texas Instruments

VIGOR # :: 3722079

Description: IC VREF SHUNT 4% 8SOIC

Catalog: PMIC - Voltage Reference

DataSheet: LM336DR-2-5 PDF

Country of origin: -

Date code: -

LM336DR-2-5 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Reference Type:	Shunt
Output Type:	Fixed
Voltage - Output (Min/Fixed):	2.49V
Voltage - Output (Max):	-
Current - Output:	10 mA
Tolerance:	±4%
Temperature Coefficient:	-
Noise - 0.1Hz to 10Hz:	-
Noise - 10Hz to 10kHz:	-
Voltage - Input:	-
Current - Supply:	-
Current - Cathode:	400 µA
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
LM336M-2.5/NOPB Match 100%	Texas Instruments IC VREF SHUNT 4% 8SOIC	LM336DR-2-5 vs LM336M-2.5/NOPB
LM336DG4-2-5 Match 100%	Texas Instruments IC VREF SHUNT 4% 8SOIC	LM336DR-2-5 vs LM336DG4-2-5
LM336MX-2.5/NOPB Match 100%	Texas Instruments IC VREF SHUNT 4% 8SOIC	LM336DR-2-5 vs LM336MX-2.5/NOPB
LM336M-2.5 Match 100%	VIGOR TWO TERMINAL VOLTAGE REFERENCE,	LM336DR-2-5 vs LM336M-2.5
LM336D-2-5 Match 100%	Texas Instruments IC VREF SHUNT 4% 8SOIC	LM336DR-2-5 vs LM336D-2-5
LM336MX-2.5 Match 100%	VIGOR LM336-2.5-N VOLTAGE REFERENCE DI	LM336DR-2-5 vs LM336MX-2.5
