NCP1562BDBR2G

Part No :: NCP1562BDBR2G

Manufacturer: VIGOR

VIGOR # :: 3849837

Description: SWITCHING CONTROLLER, VOLTAGE-MO

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: NCP1562BDBR2G PDF

Country of origin: -

Date code: -

NCP1562BDBR2G Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive, Isolation Capable
Topology:	Forward Converter
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	23.2V ~ 100V
Frequency - Switching:	246kHz ~ 1MHz
Duty Cycle (Max):	85%
Synchronous Rectifier:	Yes
Clock Sync:	Yes
Serial Interfaces:	-
Control Features:	Current Limit, Frequency Control, Ramp, Soft Start
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:	16-TSSOP
