TL5001QD

Part No :: TL5001QD

Manufacturer: VIGOR

VIGOR # :: 3850534

Description: TL5001 PWM CONTROLLER WITH WIDE

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: TL5001QD PDF

Country of origin: -

Date code: -

TL5001QD Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up, Step-Down, Step-Up/Step-Down
Output Configuration:	Positive
Topology:	Buck, Boost, Flyback
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	3.6V ~ 40V
Frequency - Switching:	20kHz ~ 500kHz
Duty Cycle (Max):	100%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Dead Time Control, Frequency Control
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
