SG3524DG4

Part No :: SG3524DG4

Manufacturer: VIGOR

VIGOR # :: 3850941

Description: SWITCHING CONTROLLER, VOLTAGE-MO

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: SG3524DG4 PDF

Country of origin: -

Date code: -

SG3524DG4 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up, Step-Down, Step-Up/Step-Down
Output Configuration:	Positive, Isolation Capable
Topology:	Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	8V ~ 40V
Frequency - Switching:	450kHz
Duty Cycle (Max):	45%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Current Limit, Frequency Control
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
SG3524DR Match 100%	Texas Instruments IC REG CTRLR MULT TOP 16SOIC	SG3524DG4 vs SG3524DR
LM25122QPWPRQ1 Match 100%	Texas Instruments WIDE-INPUT SYNCHRONOUS BOOST CON	SG3524DG4 vs LM25122QPWPRQ1
SG2524N Match 100%	Roving Networks / Microchip Technology IC REG CTRLR MULT TOPOLOGY 16DIP	SG3524DG4 vs SG2524N
SG2524DRE4 Match 100%	Texas Instruments IC REG CTRLR MULT TOP 16SOIC	SG3524DG4 vs SG2524DRE4
LM25122QPWPTQ1 Match 100%	Texas Instruments IC REG CTRLR MULT TOP 20HTSSOP	SG3524DG4 vs LM25122QPWPTQ1
SG3524NG4 Match 100%	Texas Instruments IC REG CTRLR MULT TOPOLOGY 16DIP	SG3524DG4 vs SG3524NG4
