UCC28220D

Part No :: UCC28220D

Manufacturer: Texas Instruments

VIGOR # :: 3851546

Description: IC REG CTRLR MULT TOP 16SOIC

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UCC28220D PDF

Country of origin: -

Date code: -

UCC28220D Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive
Topology:	Flyback, Forward Converter
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	8.4V ~ 14.5V
Frequency - Switching:	200kHz ~ 2MHz
Duty Cycle (Max):	75%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Ramp, Soft Start
Operating Temperature:	-40°C ~ 105°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC
