UCC3580DTR-3

Part No :: UCC3580DTR-3

Manufacturer: VIGOR

VIGOR # :: 3851985

Description: UCC3580 - SINGLE-ENDED ACTIVE CL

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UCC3580DTR-3 PDF

Country of origin: -

Date code: -

UCC3580DTR-3 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive or Negative
Topology:	Forward Converter
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	8.5V ~ 16V
Frequency - Switching:	400kHz
Duty Cycle (Max):	66%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Enable, Ramp, Soft Start
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC
