LM5022QDGSTQ1

Product image
Product thumb
Part No :

LM5022QDGSTQ1

Manufacturer
Texas Instruments
VIGOR # :

3852098

Description
IC REG CTRLR BOOST/SEPIC 10VSSOP
Catalog
PMIC - Voltage Regulators - DC DC Switching Controllers
DataSheet
LM5022QDGSTQ1 PDF
Country of origin
-
Date code
-
ads
LM5022QDGSTQ1 Specifications
Type Description
Series:Automotive, AEC-Q100
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Output Type:Transistor Driver
Function:Step-Up, Step-Up/Step-Down
Output Configuration:Positive
Topology:Boost, SEPIC
Number of Outputs:1
Output Phases:1
Voltage - Supply (Vcc/Vdd):6V ~ 60V
Frequency - Switching:200kHz ~ 2.24MHz
Duty Cycle (Max):95%
Synchronous Rectifier:No
Clock Sync:Yes
Serial Interfaces:-
Control Features:Frequency Control, Soft Start
Operating Temperature:-40°C ~ 125°C (TJ)
Mounting Type:Surface Mount
Package / Case:10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package:10-VSSOP
