MAX5020CSA+

Part No :: MAX5020CSA+

Manufacturer: Maxim Integrated

VIGOR # :: 3853714

Description: IC REG CTRLR FLYBACK 8SOIC

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: MAX5020CSA+ PDF

Country of origin: -

Date code: -

MAX5020CSA+ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Not For New Designs
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive, Isolation Capable
Topology:	Flyback
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	13V ~ 36V
Frequency - Switching:	275kHz
Duty Cycle (Max):	50%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Enable, Soft Start
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
