UCC3813PW-5G4

Part No :: UCC3813PW-5G4

Manufacturer: Texas Instruments

VIGOR # :: 3853811

Description: IC REG CTRLR MULT TOP 8TSSOP

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UCC3813PW-5G4 PDF

Country of origin: -

Date code: -

UCC3813PW-5G4 Specifications

Type	Description
Series:	-
Package:	Tray
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up, Step-Up/Step-Down
Output Configuration:	Positive
Topology:	Boost, Flyback, Forward Converter
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	3.6V ~ 12V
Frequency - Switching:	31kHz
Duty Cycle (Max):	49%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Frequency Control
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:	8-TSSOP
