TL494CNG4

Part No :: TL494CNG4

Manufacturer: Texas Instruments

VIGOR # :: 3854949

Description: IC REG CTRLR MULT TOPOLOGY 16DIP

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: TL494CNG4 PDF

Country of origin: -

Date code: -

TL494CNG4 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up, Step-Down, Step-Up/Step-Down
Output Configuration:	Positive
Topology:	Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	7V ~ 40V
Frequency - Switching:	1kHz ~ 300kHz
Duty Cycle (Max):	45%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Dead Time Control, Frequency Control
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Through Hole
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
