FAN6520BIMX

Part No :: FAN6520BIMX

Manufacturer: VIGOR

VIGOR # :: 3855663

Description: SWITCHING REGLTR, VOLTAGE-MODE

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: FAN6520BIMX PDF

Country of origin: -

Date code: -

FAN6520BIMX Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Output Type:	Transistor Driver
Function:	Step-Down
Output Configuration:	Positive
Topology:	Buck
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	4.5V ~ 5.5V
Frequency - Switching:	300kHz
Duty Cycle (Max):	100%
Synchronous Rectifier:	Yes
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Enable
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
