UC3863DWTR

Part No :: UC3863DWTR

Manufacturer: VIGOR

VIGOR # :: 3855977

Description: SWITCHING CONTROLLER

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UC3863DWTR PDF

Country of origin: -

Date code: -

UC3863DWTR Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive
Topology:	Full-Bridge, Half-Bridge, Push-Pull
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	7V ~ 22V
Frequency - Switching:	50kHz ~ 500kHz
Duty Cycle (Max):	100%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Soft Start
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	16-SOIC
